Six builds
- RP-132 3-runner, plain. 31.97 lb, 11,023 lb static, 2,646 lb dynamic, 1,323 lb racking.
- RP-132-3P 3-runner, three parallel profiles. 46.30 lb, 3,307 lb dynamic, 3,307 lb racking.
- RP-132-HP 3-runner, H-type profiles. 44.09 lb, 3,858 lb dynamic, 2,205 lb racking.
- RP-132-5R 5-runner, plain. 34.17 lb, 13,228 lb static, 2,976 lb dynamic, 1,543 lb racking.
- RP-132-5R-3P 5-runner, three parallel profiles. 48.50 lb, 3,858 lb dynamic, 3,307 lb racking.
- RP-132-5R-HP 5-runner, H-type profiles. 46.30 lb, 4,409 lb dynamic, 2,205 lb racking.
The two profile types are not a better-and-worse pair. Three parallel profiles give the higher racking figure; H-type gives the higher dynamic rating on both runner counts. Which matters depends on whether the pallet spends its life sitting on beams or moving under load.
