Stocked in North York, ON
NP-29147.24 × 31.50 × 5.31 in (1200 × 800 × 135 mm)
The NP-291 is the nine-leg member of the 47×31 nestable pair: a 1200 × 800 footprint, a ventilated deck, nine tapered legs and no runners. At 13.23 lb it is the lightest 1200-series pallet in this catalogue.
Reconstructed from the manufacturer’s own reference renders, built to the published metric dimensions and checked against them before it was rendered: close on form and exact on footprint, not a copy of their CAD. For rib profiles and tolerances, use the technical drawing.
Written within 24 hours, priced for your volume in CAD or USD, shipped from North York, ON.
No obligation. We reply with a written quotation, not a sales call.
| Size and load ratings | |
|---|---|
| Size | 47.24 × 31.50 × 5.31 in (1200 × 800 × 135 mm) |
| Wall Thickness | 2.5 to 2.6 mm |
| Dimensional Tolerance | ± 5 mm |
| Static Load | 4,409 lb (2,000 kg) |
| Dynamic Load | 2,205 lb (1,000 kg) |
| Load Basis | Ratings assume an evenly distributed load |
| Construction | |
| Deck Type | Open |
| Bottom Type | 9-Leg |
| Safety Rims | 5 mm |
| Nesting | Nestable, nine legs seat into nine deck cups |
| Material and standards | |
| Material | HDPE / PP |
| Temperature Range | −4 to +104 °F (−20 to +40 °C) |
| Resistance | Humidity, environmental pollutants, chemical acids and corrosives |
| Handling and freight | |
| Net Weight | 13.23 lb (6 ± 0.5 kg) |
| Handling | Hand pallet jack, forklift, reach truck |
| Truck Load | 2,300 pcs per jumbo trailer |
| Container Load (40 HC) | 1,760 pcs |
| Colour and branding | |
| Colour | Grey, white, navy or blue; other colours on request |
| Branding | Embossed |
| Logo Insert Areas | Long side corners 75 × 25 mm · short side corners 75 × 25 mm |
| RFID | Transponder integration available |
Ranked on the figures these products are bought on. Every model on the scale is a link, so if this one falls short on a number, the ones that clear it are a click away. Figures as published. All plastic pallets
28 models ranked by static load.
28 models ranked by dynamic load.
28 models ranked by net weight.
The range is also available with three runners. On this footprint that points at the NP-231, and it is a different moulding rather than this pallet with parts added: the NP-231 closes at 145 mm as deck 35 + leg 90 + runner 20, where this one closes at 135 as deck 35 + leg 100. Fitting runners to this pallet is not an option we can offer.
2,300 per jumbo trailer and 1,760 per 40 ft high-cube, for the complete pallet with nothing to assemble. The reason, put plainly: nestable, reduces freight costs.
1,820 and 1,410
If empties come back to you, that first line is the case for this pallet.
Both figures are stated identically by the specification table and the datasheet, with nothing to reconcile. Both assume an evenly distributed load and fall with a concentrated or point load.
Against its own runner sibling the NP-231, this one gives up 1,102 lb (500 kg) of static and 551 lb (250 kg) of dynamic, and the racking rating entirely. What it buys is 4.4 lb off the pallet and 480 more per trailer. That is the trade, and which way it falls depends on whether your empties travel.
Light-goods export and production-line work, and bulky but light loads in particular. At just over 13 lb an empty one is the easiest 1200-series pallet in this catalogue for one person to move by hand.
High-density polyethylene and polypropylene, resistant to humidity, airborne environmental pollutants, and chemical acids and corrosives. It is also maintenance free and hygienic and clean. Safety rims, 5 mm, to stop a load creeping on the deck.
Overall height is 5.31 in (135 mm), which the drawing splits into a 35 mm deck over 100 mm legs, with a wall thickness of 2.5 to 2.6 mm taken at two points on the moulding. Serviceable from −4 °F to +104 °F (−20 to +40 °C). Supplied in grey, white, navy or blue, with other colours to order. Dimensions carry a ±5 mm production tolerance.
Handled with a hand pallet jack, forklift or reach truck.
Logo embossed, at two positions, and RFID transponders can be integrated for pool tracking.
No insert is offered on the centre leg. Printing is sometimes listed as an option for this pallet, but the labelling table marks only embossing, so embossing is what we publish. If you need a printed mark, ask us and we will confirm rather than assume.
In this film
Answered from the NP-291’s published specification. Anything else, ask on the quotation and it is answered in writing.
4,409 lb (2,000 kg) static and 2,205 lb (1,000 kg) dynamic. Ratings assume an evenly distributed load.
47.24 × 31.50 × 5.31 in (1200 × 800 × 135 mm). Dimensional tolerance ± 5 mm.
13.23 lb (6 ± 0.5 kg) net.
9-Leg base under a open deck. Nestable, nine legs seat into nine deck cups. Handled by hand pallet jack, forklift, reach truck.
HDPE / PP. Rated for −4 to +104 °F (−20 to +40 °C). Resistant to humidity, environmental pollutants, chemical acids and corrosives.
2,300 pcs per jumbo trailer. 1,760 pcs per 40 ft high-cube container.
Colours: Grey, white, navy or blue; other colours on request. Logo: embossed. Insert areas: Long side corners 75 × 25 mm · short side corners 75 × 25 mm. RFID: transponder integration available.
Yes. The NP-291 datasheet is a PDF on this page with the full specification table and the load figures.
Prices are quoted, not listed, because they depend on volume, build and destination. A written quotation follows within 24 hours, in CAD or USD, shipped from North York, ON.
