Why no runners
Because there are none, a pallet jack can enter from all four sides. On the three-runner FG-131 a jack comes in across the runners only, from two. This is the same trade the 47×31 FG-291 makes, on the larger deck.
48×40 Food-Grade Pallet, Closed Deck, 9-Leg
FG-19147.24 × 39.37 × 5.12 in (1200 × 1000 × 130 mm)
The FG-191 is the 48×40 runnerless food-grade pallet: nine legs, a smooth entirely closed deck, and nothing spanning between the legs.
Reconstructed from the manufacturer’s own reference renders, built to the published metric dimensions and checked against them before it was rendered: close on form and exact on footprint, not a copy of their CAD. For rib profiles and tolerances, use the technical drawing.
- Static Load
- 11,023 lb5,000 kgJoint 3rd highest of 28 plastic pallets
- Dynamic Load
- 2,756 lb1,250 kgJoint 7th highest of 28 plastic pallets
- Net Weight
- 36.38 lb16.5 ± 0.5 kg24th lightest of 28 plastic pallets
Request a quotation
Written within 24 hours, priced for your volume in CAD or USD, shipped from North York, ON.
No obligation. We reply with a written quotation, not a sales call.
Figures for the base build. 2 builds compared in the specification
Specification
| Size and load ratings | |
|---|---|
| Size | 47.24 × 39.37 × 5.12 in (1200 × 1000 × 130 mm) |
| As-Moulded Size | 1196 × 997 × 130.5 mm, against the nominal 1200 × 1000 × 130 |
| Dimensional Tolerance | ± 5 mm |
| Static Load | 11,023 lb (5,000 kg) |
| Dynamic Load | 2,756 lb (1,250 kg) |
| Load Basis | Ratings assume an evenly distributed load |
| Construction | |
| Deck Type | Closed |
| Bottom Type | 9-Leg |
| Construction | Fully closed, no cavities; no metal reinforcement in the body; corners rounded to R28 |
| Safety Rims | 7 mm |
| Material and standards | |
| Material | Food-grade HDPE |
| Temperature Range | −4 to +86 °F (−20 to +30 °C) |
| Resistance | Humidity, environmental pollutants, chemical acids and corrosives |
| Wash-Down | Easy-wash, resistant to industrial detergents |
| Handling and freight | |
| Net Weight | 36.38 lb (16.5 ± 0.5 kg) |
| Handling | Hand pallet jack, forklift, reach truck |
| Pallet Jack Access | All four sides, no runners to block entry |
| Truck Load | 650 pcs per jumbo trailer |
| Container Load (40 HC) | 550 pcs |
| Colour and branding | |
| Colour | Grey, white, navy or blue; other colours on request |
| Branding | Printed |
| Logo Insert Areas | Long side corners 105 × 95 mm · short side corners 90 × 80 mm · centre leg 90 × 80 mm |
| RFID | Transponder integration available |
Food-grade HDPE selected. SKU FG-191.
Where the FG-191 sits among 28 plastic pallets
Ranked on the figures these products are bought on. Every model on the scale is a link, so if this one falls short on a number, the ones that clear it are a click away. Figures as published. All plastic pallets
28 models ranked by static load.
- 16,535 lb7,500 kg
- 13,228 lb6,000 kg
- 11,023 lb5,000 kg
- 8,818 lb4,000 kg
- 5,512 lb2,500 kg
- 4,409 lb2,000 kg
- 2,205 lb1,000 kg
- 1,764 lb800 kg
28 models ranked by dynamic load.
- 3,968 lb1,800 kg
- 3,307 lb1,500 kg
- 3,031 lb1,375 kg
- 2,756 lb1,250 kg
- 2,646 lb1,200 kg
- 2,646 lb1,200 kg
- 2,205 lb1,000 kg
- 1,543 lb700 kg
- 882 lb400 kg
28 models ranked by net weight.
- 6.39 lb2.9 ± 0.5 kg
- 13.23 lb6 ± 0.5 kg
- 14.33 lb6.5 ± 0.5 kg
- 15.43 lb7 ± 0.5 kg
- 15.87 lb7.2 ± 0.5 kg
- 17.64 lb8 ± 0.5 kg
- 18.08 lb8.2 ± 0.5 kg
- 19.84 lb9 ± 0.5 kg
- 20.28 lb9.2 ± 0.5 kg
- 22.49 lb10.2 ± 0.5 kg
- 26.46 lb12 ± 0.5 kg
- 26.90 lb12.2 ± 0.5 kg
- 29.76 lb13.5 kg
- 30.86 lb14 ± 0.5 kg
- 31.97 lb14.5 ± 0.5 kg
- 34.17 lb15.5 ± 0.5 kg
- 36.38 lb16.5 ± 0.5 kg
- FG-191this model
- 39.68 lb18 ± 0.5 kg
- 40.79 lb18.5 ± 0.5 kg
- 48.50 lb22 ± 0.5 kg
- 60.63 lb27.5 ± 0.5 kg
Hygiene
The deck is smooth and entirely closed, with no cavities, so dust has nowhere to collect and the pallet dries as readily as it washes. It is easy-wash and resistant to industrial detergents, and no metal reinforcement is used in the body, which matters where metal detection or X-ray screening sits in the line.
Suited to food production, pharmaceutical handling and isolated environments.
Two builds
- FG-191 food-grade HDPE, 36.38 lb
- FG-191-PP food-grade polypropylene, 35.27 lb, and it takes
+140 °F rather than +86 °F
Ratings, footprint, deck and loading quantities are identical between them.
Ratings
- Static load 11,023 lb (5,000 kg)
- Dynamic load 2,756 lb (1,250 kg)
Both assume an evenly distributed load and fall with a concentrated or point load. The three-runner FG-131 carries far more, 16,535 lb static and a published racking figure; the runners are what earn that, and this build trades them for four-sided jack access.
A note on the temperature rating
Three different figures are in circulation for the HDPE build: −25 to +60 °C, −20 to +40, and the datasheet figure of −20 to +30. We publish −4 °F to +86 °F (−20 to +30 °C), the narrowest of the three, so nothing here promises more than the most cautious figure does. It is also the figure every other food-grade HDPE pallet in this catalogue carries. If you are running near either end of that band, ask us and we will confirm.
The PP build has no such disagreement: −4 °F to +140 °F (−20 to +60 °C) wherever it is stated.
Construction and dimensions
Nominal 47.24 × 39.37 × 5.12 in (1200 × 1000 × 130 mm). The drawing gives the as-moulded figures as 1196 × 997 × 130.5 mm and splits the height into a 38.9 mm deck over 91.6 mm legs. Corners are rounded to R28, the same as the 48×40 three-runner pallet.
Safety rims of 7 mm. Supplied in grey, white, navy or blue, with other colours to order. Dimensions carry a ±5 mm production tolerance. Resistant to humidity, airborne environmental pollutants, and chemical acids and corrosives.
Handled with a hand pallet jack, forklift or reach truck.
Identification
Logo printed, at three positions, and RFID transponders can be integrated for pool tracking.
- Long side, corner blocks 105 × 95 mm
- Short side, corner blocks 90 × 80 mm
- Centre leg 90 × 80 mm
Embossing is not offered: the labelling table marks that column with a cross rather than a dash, and both datasheets name printing alone.
The FG-191 on film
In this film
Frequently asked questions
Answered from the FG-191’s published specification. Anything else, ask on the quotation and it is answered in writing.
How much weight can the 48×40 food-grade pallet (FG-191) hold?
11,023 lb (5,000 kg) static and 2,756 lb (1,250 kg) dynamic. Ratings assume an evenly distributed load.
What are the dimensions of the 48×40 food-grade pallet (FG-191)?
47.24 × 39.37 × 5.12 in (1200 × 1000 × 130 mm). As moulded: 1196 × 997 × 130.5 mm, against the nominal 1200 × 1000 × 130. Dimensional tolerance ± 5 mm.
How much does the 48×40 food-grade pallet (FG-191) weigh?
36.38 lb (16.5 ± 0.5 kg) net.
What kind of base does the 48×40 food-grade pallet (FG-191) have?
9-Leg base under a closed deck. Pallet jack access: all four sides, no runners to block entry. Handled by hand pallet jack, forklift, reach truck.
What is the 48×40 food-grade pallet (FG-191) made of?
Food-grade HDPE. Rated for −4 to +86 °F (−20 to +30 °C). Resistant to humidity, environmental pollutants, chemical acids and corrosives. Easy-wash, resistant to industrial detergents.
How many 48×40 food-grade pallet (FG-191) fit on a truck or in a container?
650 pcs per jumbo trailer. 550 pcs per 40 ft high-cube container.
Can the 48×40 food-grade pallet (FG-191) be supplied in our colour, with our logo?
Colours: Grey, white, navy or blue; other colours on request. Logo: printed. Insert areas: Long side corners 105 × 95 mm · short side corners 90 × 80 mm · centre leg 90 × 80 mm. RFID: transponder integration available.
Is there a datasheet for the 48×40 food-grade pallet (FG-191)?
Yes. The FG-191 datasheet is a PDF on this page with the full specification table and the load figures. Each of the 2 builds has its own sheet; choose the build to download the matching one.
How much does the 48×40 food-grade pallet (FG-191) cost?
Prices are quoted, not listed, because they depend on volume, build and destination. A written quotation follows within 24 hours, in CAD or USD, shipped from North York, ON.
