47×24 Concrete Wall Form Panel

WF-052447.24 × 23.62 in (1200 × 600 mm)

The WF-0524 is the full-width panel: at 1200 mm it is the widest in the range and the one that covers ground.

Panel Width
47.24 in1200 mmWidest of 6 concrete wall forms

Request a quotation

Written within 24 hours, priced for your volume in CAD or USD, shipped from North York, ON.

No obligation. We reply with a written quotation, not a sales call.

Specification

Technical specifications
Size and load ratings
Size47.24 × 23.62 in (1200 × 600 mm)
Panel Width47.24 in (1200 mm)
Construction
System TypeModular interlocking wall form panel
ConstructionOne-piece moulding, rib grid behind the forming face, tie slots down both long edges
Concrete FinishSmooth as-struck; no further surface treatment
Material and standards
MaterialPP, ABS
ResistanceDoes not rust, absorb water or swell
Release AgentNot required
BreakageBroken forms replaced with new at the end of the project
ReuseReusable
Reuse CyclesMinimum 100 uses, stated rather than tested
Handling and freight
Weight70% lighter than steel formwork
HandlingSet and struck by hand
LiftingNo tower crane required to move it
ApplicationConcrete walls, foundations and vertical structures
Colour and branding
ColourBlack or white
Download datasheetWF-0524 · PDF · full specification
